DNT 950DNT 950
Fixed Station DNT 950
DOS Fixed Station Data Collection Computer
PRODUCT SUMMARY:

The DNT 950 is a DOS compatible, Intel 80386 based data collection computer designed to be modular, expandable and easily programmed in common languages like "C" or BASIC. The DNT 950 supports flexible input and output options to allow it to address a wide variety of applications. Its rugged and durable design make it a favorite in the manufacturing industry. With its Ethernet and RF 802.11b wireless options no additional wiring expertise is necessary to add it to your shop floor environment.

To order an evaluation of the DNT 950 contact info@data-net.com. This evaluation unit will come fully equipped with a single user version of Co-Log/Open, a DNT 950, power supply and scanning device. You can order an evaluation system at no charge for a 30-day review.

SPECIFICATIONS:

Display/Tone
  • 640 x 480 B&W or Color VGA LCD with vacuum fluorescent backlight;
  • or 2 line, 40 character per line LCD with electroluminescent backlight;
  • or Blank insert;
  • 2 LEDs - 1 green, 1 red;
  • Beeper with software adjustable tone and volume
Keyboard
  • Dust & liquid spill resistant;
  • 10,000,000 actuation operating life Elastomer;
  • 56 key alphanumeric, 12 user definable function keys (with changeable labels): A-Z, 0-9, -, ., SPACE, BACKSPACE, ESCAPE, ENTER, SHIFT;
  • or 28 key numeric, 12 user definable function keys (with changeable labels): 0-9, -, ., SPACE, BACKSPACE, ESCAPE, ENTER;
  • or None, blank insert;
  • Separate alpha and numeric keys
Packaging
  • Factory rugged polycarbonate;
  • 8" wide x 11" high x 5" deep;
  • 8 lbs., approximate;
  • Standard wall mount, table mount optional;
  • Integral swipe reader mounting
Environment
  • 0 to 50 C;
  • 5 - 95% relative humidity, non-condensing
Microprocessor / Memory
  • Intel 80386ex;
  • 1M SRAM standard, 2M and 4M optional;
  • Flash - 240k standard, 8M, 16M and 24M available
Communications
  • RS-422 multi-drop;
  • RS-232 point-to-point;
  • Spread spectrum radio frequency;
  • Internal PC/104 option bus;
  • PCMCIA option, internal on PC/104 bus
Power
  • 24 VDC input;
  • Integral battery and power supply;
  • INPUT/OUTPUT;
  • RS-232 general-purpose port (COM2);
  • RS-232 / RS-422 / RS-485 port (COM1);
  • Dual barcode input;
  • 4 switch inputs;
  • 4 relay outputs, 2 AMP @ 24 VDC or 0.5 AMP @ 120 VAC, double pole
Options
  • Infra-red, 0.13mm, sealed sapphire tip wand;
  • Visible, 0.19mm, sealed sapphire tip wand;
  • Laser scanner;
  • Visible, 0.19mm sealed swipe reader;
  • Infra-red, 0.19mm sealed swipe reader;
  • Magnetic swipe reader, ABA track 2, F2F;
  • Table mount bracket;
  • F950 110 VAC single terminal power transformer;
  • F953 220 VAC single terminal power transformer;
  • F71 110 VAC, 8 terminal, power and communications wiring distribution box;
  • F73 220 VAC, 8 terminal, power and communications wiring distribution box

APPLICATIONS:

The DNT 950 can be used for the following applications:
