Dimensions
|
-
7.0 in. H x 3.5 in. W x 8.8 in. L / 178 mm H x 89
mm W x 224 mm L
|
|
Weight
|
-
Batch: 24 oz./672 gm with battery
-
Wireless: 26 oz./728 gm with battery
|
|
Operating
Temperature
|
- -13°
to 122° F / -25° to 50° C
|
|
Storage
Temperature
|
-
-13°
to 140° F / -25° to 60° C
|
|
Humidity
|
- 95%
relative humidity, non-condensing
|
|
Drop
Spec
|
-
Multiple 4 ft. / 1.2 m drops to concrete
|
|
Environmental
Sealing
|
-
MIL-STD-810E / SAEJ1211 / IP54
|
|
ESD
|
-
15KV electrostatic discharge to all surfaces without
loss of data
|
|
Keyboard,
Standard
|
-
46 large, hard, alphanumeric keys
|
|
Display
|
-
16-line by 21-character FSTN LCD, back light, reverse
video, double-high and double-wide characters
|
|
Power
|
-
Removable, rechargeable battery pack
|
|
CPU
|
|
|
Operating
System
|
|
|
ROM
|
-
128 KB EPROM (DOS, Terminal Diagnostics)
|
|
RAM
|
-
640 KB Standard (up to 6.1 MB for batch option)
|
|
Non-Volatile
Memory
|
-
256 KB Standard (up to 1.2 MB for RF option)
|
|
Communications
|
-
Network: Spectrum24® 11 Mbps, internal antenna
|
|
Options
|
-
Cradles: Single slot and four-slot cradles available;
-
4-Slot Battery Charger Recharges multiple batteries;
-
Battery Adapter: Used with Universal Battery Charger
|
